Single girder Overhead crane
Single beam bridge crane is a kind of lifting equipment that is erected horizontally over workshops, warehouses and stockyards to lift materials.
Because its two ends are located on tall concrete columns or metal supports, it looks like a bridge. The bridge of the single beam bridge crane runs longitudinally along the track laid on the viaduct on both sides, which can make full use of the space under the bridge to lift materials without being hindered by ground equipment. It is a kind of lifting machinery in the range of use.
Technical parameter:
| LD Single girder overhead crane | ||||||
| Lifting Capacity (t) | Span (m) | Lifting Height (m) | Hoist Lifting speed (m/min) |
Hoist running speed (m/min) |
Crane running speed (m/min) |
Work duty |
| 1 | 7.5~28.5 | 6~18 | 3.5~8 | 20~30 | 20~60 | A3~A4 |
| 2 | 7.5~28.5 | 6~18 | 3.5~8 | 20~30 | 20~60 | A3~A4 |
| 3.2 | 7.5~28.5 | 6~18 | 3.5~8 | 20~30 | 20~60 | A3~A4 |
| 5 | 7.5~28.5 | 6~18 | 3.5~8 | 20~30 | 20~60 | A3~A4 |
| 10 | 7.5~28.5 | 6~18 | 3.5~8 | 20~30 | 20~60 | A3~A4 |
| 12.5 | 7.5~28.5 | 6~18 | 3.5~8 | 20~30 | 20~60 | |
| 16 | 7.5~28.5 | 6~18 | 3.5~8 | 20~30 | 20~60 | |
| 20 | 7.5~28.5 | 6~18 | 3.5~8 | 20~30 | 20~60 | |
| If you have other requirements or know the specific parameters, please call and ask Sinnone crane | ||||||
