Shaft Pin Load Cell
|
Product Name
|
Shaft Pin Load Cell
|
|
Model Number
|
SNH-9A
|
|
Comprehensive Precision
|
0.05%FS
|
|
Sensitivity
|
1.5mV/V
|
|
Creep
|
±0.05%FS/30min
|
|
Zero Output
|
±1%FS
|
|
Temperature effect on zero
|
±0.05%FS/10℃
|
|
Temperature effect on output
|
±0.05%FS/10℃
|
|
Operating temperature range
|
-20℃-+65℃
|
|
Input Resistance
|
750±15Ω
|
|
Output Resistance
|
700±5Ω
|
|
Insulation Resistance
|
>5000MΩ
|
|
Safe Load Limit
|
150%FS
|
|
Bridge Voltage
|
advise 10V DC
|
|
Mode of connection
|
Input+ : Red, Input- : Black, Output+ : Green, Output- : White
|
|
Stainless Steel
|
Alloy Steel or Stainless Steel
|
